NEWToggle Switch 6pin

Toggle Switch 6pin

(0 reviews)✓ In Stock
৳30৳30-0%

Product Overview: 6-Pin DPDT Toggle Switch The 6-Pin Toggle Switch is a heavy-duty DPDT (Double Pole Double Throw) switch designed for controlling two separate circuits simultaneously. Unlike a basic switch, the 6-pin configuration allows you to flip two independent "poles" at the same time with a single lever. This makes it the industry standard for motor polarity reversal (Forward/Reverse), dual-power source selection, and complex industrial control panels. Technical Specifications Feature Specification Switch Type Toggle (Lever Action) Configuration DPDT (Double Pole, Double Throw) Number of Pins 6 Solder or Screw Terminals Current Rating 15A @ 125V AC / 10A @ 250V AC DC Voltage Supports up to 28V DC Mechanical Life 100,000 Cycles Mounting Diameter 12mm (Standard Round Hole) Contact Material Silver-plated Brass / Copper Key Features Dual Circuit Control: Operates as two separate switches controlled by one lever, enabling simultaneous switching of two different voltage lines. Motor Reversing Capability: The 6-pin layout is perfectly designed for "H-Bridge" wiring to reverse the direction of DC motors. Three-Position Options: Often available in ON-ON or ON-OFF-ON (Center Off) versions for specialized control. All-Metal Lever: Features a rugged chrome-plated brass lever for high durability in harsh environments. Easy Installation: Includes a mounting nut and locking washer for secure attachment to any 12mm panel hole. Pin Configuration Center Pins (Common): The main power inputs for Pole 1 and Pole 2. Outer Pins: The two sets of output paths. Flipping the switch connects the center pins to either the top pair or bottom pair of outer pins

Quantity:
1
4000 available
Buy Now

Product Overview: 6-Pin DPDT Toggle Switch The 6-Pin Toggle Switch is a heavy-duty DPDT (Double Pole Double Throw) switch designed for controlling two separate circuits simultaneously. Unlike a basic switch, the 6-pin configuration allows you to flip two independent "poles" at the same time with a single lever. This makes it the industry standard for motor polarity reversal (Forward/Reverse), dual-power source selection, and complex industrial control panels. Technical Specifications Feature Specification Switch Type Toggle (Lever Action) Configuration DPDT (Double Pole, Double Throw) Number of Pins 6 Solder or Screw Terminals Current Rating 15A @ 125V AC / 10A @ 250V AC DC Voltage Supports up to 28V DC Mechanical Life 100,000 Cycles Mounting Diameter 12mm (Standard Round Hole) Contact Material Silver-plated Brass / Copper Key Features Dual Circuit Control: Operates as two separate switches controlled by one lever, enabling simultaneous switching of two different voltage lines. Motor Reversing Capability: The 6-pin layout is perfectly designed for "H-Bridge" wiring to reverse the direction of DC motors. Three-Position Options: Often available in ON-ON or ON-OFF-ON (Center Off) versions for specialized control. All-Metal Lever: Features a rugged chrome-plated brass lever for high durability in harsh environments. Easy Installation: Includes a mounting nut and locking washer for secure attachment to any 12mm panel hole. Pin Configuration Center Pins (Common): The main power inputs for Pole 1 and Pole 2. Outer Pins: The two sets of output paths. Flipping the switch connects the center pins to either the top pair or bottom pair of outer pins
