LIMITEDRocker Switch Big 4 Pins Red

Rocker Switch Big 4 Pins Red

(0 reviews)✓ In Stock
৳30৳30-0%

Product Overview: Big Red 4-Pin Rocker Switch (DPST) The Big Red 4-Pin Rocker Switch is a heavy-duty power control switch designed for high-current applications. Featuring an integrated Neon or LED indicator, it provides clear visual confirmation when the circuit is active. This switch is commonly used in power strips, industrial machinery, and home appliances as a main power toggle. Its DPST (Double Pole Single Throw) configuration allows it to disconnect both the "Live" and "Neutral" wires simultaneously for enhanced safety. Technical Specifications Feature Specification Switch Type Rocker (On-Off) Configuration DPST (Double Pole, Single Throw) Number of Pins 4 Pins Voltage Rating 15A 250V AC / 20A 125V AC Illumination Built-in Red Neon or LED (220V/110V dependent) Contact Resistance ≤ 50 mΩ Insulation Resistance ≥ 100 MΩ Dielectric Strength 1500V AC / 1 minute Mechanical Life > 50,000 Cycles Electrical Life > 10,000 Cycles Key Features Dual Line Switching: Disconnects both lines of a circuit simultaneously, ensuring total isolation from the power source. Snap-In Mounting: Designed for quick and easy installation into standard rectangular panel cutouts without the need for screws. Internal Illumination: The transparent red actuator glows when the switch is in the "ON" position, making it easy to locate in low-light environments. Durable Construction: Built with flame-retardant plastic and silver-plated copper terminals for high conductivity and heat resistance. High Load Capacity: Rated for up to 20A, making it suitable for heaters, motors, and high-power DIY projects. Pin Configuration & Wiring Pins 1 & 2 (Top Pair): Generally the "Input" from your power source. Pins 3 & 4 (Bottom Pair): Generally the "Output" to your load (device).

Quantity:
1
3000000 available
Buy Now

Product Overview: Big Red 4-Pin Rocker Switch (DPST) The Big Red 4-Pin Rocker Switch is a heavy-duty power control switch designed for high-current applications. Featuring an integrated Neon or LED indicator, it provides clear visual confirmation when the circuit is active. This switch is commonly used in power strips, industrial machinery, and home appliances as a main power toggle. Its DPST (Double Pole Single Throw) configuration allows it to disconnect both the "Live" and "Neutral" wires simultaneously for enhanced safety. Technical Specifications Feature Specification Switch Type Rocker (On-Off) Configuration DPST (Double Pole, Single Throw) Number of Pins 4 Pins Voltage Rating 15A 250V AC / 20A 125V AC Illumination Built-in Red Neon or LED (220V/110V dependent) Contact Resistance ≤ 50 mΩ Insulation Resistance ≥ 100 MΩ Dielectric Strength 1500V AC / 1 minute Mechanical Life > 50,000 Cycles Electrical Life > 10,000 Cycles Key Features Dual Line Switching: Disconnects both lines of a circuit simultaneously, ensuring total isolation from the power source. Snap-In Mounting: Designed for quick and easy installation into standard rectangular panel cutouts without the need for screws. Internal Illumination: The transparent red actuator glows when the switch is in the "ON" position, making it easy to locate in low-light environments. Durable Construction: Built with flame-retardant plastic and silver-plated copper terminals for high conductivity and heat resistance. High Load Capacity: Rated for up to 20A, making it suitable for heaters, motors, and high-power DIY projects. Pin Configuration & Wiring Pins 1 & 2 (Top Pair): Generally the "Input" from your power source. Pins 3 & 4 (Bottom Pair): Generally the "Output" to your load (device).
