Mini360 Mini-360 DC-DC HM Buck Converter Step Down
Key Features Synchronous Rectification: Uses a specialized control chip and an integrally molded power inductor to achieve up to 96% efficiency, significantly outperforming standard linear regulators. Ultra-Compact Design: Its "mini" form factor makes it ideal for flight controllers, portable electronics, and DIY robotics where every millimeter counts. High Switching Frequency: Operates at 340KHz, which allows for a stable output with very low ripple (30mV), ensuring clean power for sensitive components. Wide Voltage Range: Converts any input between 4.75V and 23V down to a user-adjustable output of 1.0V to 17V. Thermal Durability: Engineered to function in harsh environments, with an operational temperature range from -40°C to +85°C. Technical Specifications Component Specification Module Type Non-isolated step-down (Buck) Input Voltage 4.75V – 23V Output Voltage 1.0V – 17V (Adjustable) Current Output 1.8A (Continuous) / 3A (Peak) Efficiency 96% Maximum Output Ripple 30mV (at no load) Regulation ±0.5% Load / ±2.5% Voltage Usage Notes Voltage Adjustment: The output is adjusted via the tiny onboard potentiometer. Since this is a buck converter, the input voltage must always be at least 1.5V higher than the desired output voltage. Current Handling: For continuous operation at the 3A peak, additional cooling or heat sinking is recommended; otherwise, stick to the 1.8A continuous rating to prevent overheating.
