N20 12V 200 RPM Micro Metal DC Gear Motor

৳ 300.00

Earn 300 ROBO-Points worth ৳ 3.00


Features : dc gear motor price in bd

  1. This is a DC Mini Metal Gear Motor, ideal for making robots
  2. Lightweight, high torque and low RPM.
  3. Fine craftsmanship, durable, not easy to wear.
  4. With excellent stall characteristics, can climb hills easily.
  5. You can also easily mount a wheel on the motor’s output shaft.



General Specification

Model No. N20-12V-200
No Load Current (mA) 0.06 A
Stall Current (A) 0.75
Rated Torque(kg-cm) 0.52
Stall Torque(Kg-Cm) 1.8
Motor Body Size (Diameter) (mm) 12
Operating Voltage (VDC) 6 ~ 12
Rated Operating Voltage (VDC) 12
No load Speed (RPM) 200
Rated Speed (RPM) 200
Shaft Type D-type
Single Side
Shaft Diameter (mm) 3
Weight (gm) 12
Output Axial Length (mm) 10
Fuselage w/o Shaft Length 26
Screw Size M3
Motor Type Single Shaft
Shipment Weight 0.016 kg
Shipment Dimensions 6 × 6 × 2 cm

Best product DC gear motor price in bd N20 12V 200 RPM Micro Metal. Here, This product is available at Robo Tech Valley.
